Cast resin branch joint with EG resin
for plastic cables and wires
Universally applicable for branching cables and wires with PVC, PE, XLPE and EPR insulation (e.g. N(A)YY, NYM, TT) with and without concentric conductors. Suitable for single branch terminals on copper and aluminum conductors.
Details
Characteristics
- Compact dimensions
- Splice position visible before potting
- High-quality, transparent, impact-resistant plastic molded shells
- Large filling opening for easy potting
- Resistant to chemical influences
- Resistant to alkaline earths
- Stabilized against UV rays
- Longitudinally and transversely watertight
- High electrical insulation values
- High mechanical strength
- Immediately ready for use
- Simple, quick installation, saving time and costs
Application/suitability
- Indoor
- Outdoor
- Ground
- Water
- Installation ducts Voltage level
- U0/U (Um) 0.6/1 (1.2) kV Test standards
- DIN EN 50393 (corresponds to VDE 0278)
Storage time/durability
- Casting resin up to 40 months
Scope of delivery
Hydrolysis-resistant PUR casting resin EG, measured and ready to mix in a practical
two-chamber mixing bag, transparent plastic molded tray, sealing plug,
Filling and venting funnel, PVC insulating tape, protective gloves, installation instructions
Optional accessories:
- AK screw-type branch terminal (see connection technology)
- Cable branch terminal KP (see connection technology)
- HE 1/70/150 cable branch terminal (see connection technology)
- Overhead cable clamp FK (see connection technology)
- UNIVERSAL CLEANER 121 cleaner (see accessories)
